Coconut water disc separator
--------------------------------------------------------------------------
Model PDSM-DN separator is mainly used for clarifying and defatting of milk,It is also used for the similar oil to clarify the Liquid-Liquid-Solid three-phase materials ,it is also widely used in the coconut water to separate the fat and impurity.
The machine is one kind of rotary machine with high speed, After accurate dynamic balancing, it can run for long time with low vibration, safety and security.
The design, product and acceptance are conformed to the standard of JB/T8103.3 “Disc Separator-Part 3:Milk disc separator”.
Technical parameter:
| Model |
PDSM1000-DN
|
PDSM3000-DN
|
PDSM5000-DN
|
PDSM10000-DN
|
| Discharging type |
Variable capacity discharging |
| Rated capacity |
l/h |
1000 |
3000 |
5000 |
10000 |
| Motor power |
kw |
4 |
11 |
15 |
18.5 |
| N.W. |
kg |
371 |
635 |
970 |
1305 |
| Dimension |
LxWxH mmxmmxmm
|
885x854x1082 |
1120x850x1237 |
1264x1033x1471 |
1766x948x1589 |
| Dimension of package |
LxWxH mmxmmxmm
|
1290x1150x1400 |
1250x1150x1500 |
1700x1490x1780 |
2066x1350x1890 |
| G.W. |
kg |
536 |
895 |
1270 |
1600 |
--------------------------------------------------------------------------
